| Operating weight | 2850kg |
| Maximum operating weight | 3450kg |
| Front axle weight | 1350kg |
| Rear axle weight | 1500kg |
| Static linear load | 110/122N/cm |
| Working speed | \km/h |
| Gradeability | 30% |
| Minimum turning radius | 3700outer |
| Minimum ground clearance | 275mm |
| Wheel base | 1773mm |
| Steering angle° | ±32 |
| Oscillation angle° | ±8 |
| Vibration frequency | 63/67Hz |
| Nominal amplitude | 0.5mm |
| Excitation force | 36/41high/low frequency |
| Drum diameter | 720mm |
| Drum width | 1200mm |
| Model | D1703 |
| Emission | EU Stage IIIA |
| Rated Power | 25.6kW |
| Rated speed | 2600r/min |
| Fuel tank | 35L |
| Urea box | \L |
| Water tank | 165+45L |
| Operating speed | 0-10km/h |
| Drive speed | \km/h |
| Vibration frequency | \Hz |
| Amplitude | \mm |
| Driving mode | \ |
| Electrical system | \V |
| Brand and type | \ |
| Power/Speed | \kW/rpm |
| Fuel tank | \L |
| Hydraulic oil tank | \L |
| Water tank | \L |
| Overall Dimensions | \mm |
