| Operating weight | 4000kg |
| Maximum operating weight | 4100kg |
| Front axle weight | 2100kg |
| Rear axle weight | 1900kg |
| Static linear load | 152N/cm |
| Working speed | \km/h |
| Gradeability | 30% |
| Minimum turning radius | 4100outer |
| Minimum ground clearance | 350mm |
| Wheel base | 1980mm |
| Steering angle° | ±32 |
| Oscillation angle° | ±8 |
| Vibration frequency | 53/60Hz |
| Nominal amplitude | 0.5mm |
| Excitation force | 42/53high/low frequency |
| Drum diameter | 920mm |
| Drum width | 1380mm |
| Model | V2403 |
| Emission | EU Stage V/EPA TIER4f |
| Rated Power | 33.6kW |
| Rated speed | 2400r/min |
| Fuel tank | 55L |
| Urea box | \L |
| Water tank | 235+45L |
| Operating speed | \km/h |
| Drive speed | \km/h |
| Vibration frequency | \Hz |
| Amplitude | \mm |
| Driving mode | \ |
| Electrical system | \V |
| Brand and type | \ |
| Power/Speed | \kW/rpm |
| Fuel tank | \L |
| Hydraulic oil tank | \L |
| Water tank | \L |
| Overall Dimensions | \mm |
