| Operating weight | 1700kg |
| Maximum operating weight | \kg |
| Front axle weight | 800kg |
| Rear axle weight | 900kg |
| Static linear load | 87/98N/cm |
| Working speed | 0～11km/h |
| Gradeability | \% |
| Minimum turning radius | 2240/3140outer |
| Minimum ground clearance | 250mm |
| Wheel base | 1550mm |
| Steering angle° | ±32 |
| Oscillation angle° | \ |
| Vibration frequency | 48/65Hz |
| Nominal amplitude | 0.4mm |
| Excitation force | \high/low frequency |
| Drum diameter | 620mm |
| Drum width | 900mm |
| Model | KUBOTA D1105 |
| Emission | \ |
| Rated Power | 16.3kW |
| Rated speed | 2600r/min |
| Fuel tank | \L |
| Urea box | \L |
| Water tank | \L |
| Operating speed | \km/h |
| Drive speed | \km/h |
| Vibration frequency | \Hz |
| Amplitude | \mm |
| Driving mode | \ |
| Electrical system | \V |
| Brand and type | \ |
| Power/Speed | \kW/rpm |
| Fuel tank | \L |
| Hydraulic oil tank | \L |
| Water tank | \L |
| Overall Dimensions | \mm |
