Configuration selling point
The special engine reasonably matches with the traveling hydraulic system for high reliability;Ease of maintenance and operation comfort
The maintenance points are arranged reasonably, and the hood can be opened for easy maintenance.Adaptability to diverse working conditions
With small working radius, it is suitable for work in a narrow area, and has been used widely in ditch backfilling, underground work, construction of road corners and rural construction etc.| External dimensions | 1100*840*1820mm |
| Engine brand | Changchai |
| Power/speed | 6/3600kW/rpm |
| Operating weight | 542kg |
| Front and Rear Static Linear Loads | 65N/cm |
| Vibration frequency low/high | 70Hz |
| Excitation force | 16kN |
| Amplitude | 0.5mm |
| Gradeability | 0.3 |
| Speed | 0-3km/h |
| Emissions | Eu stage IIIndicated as per China standards |
