Configuration selling point
The remote control system with the capability of automatic control ensures stable performance, and the special resin scraper has a long wear lifeEase of maintenance and operation comfort
The maintenance points are arranged reasonably, and the hood can be opened for easy maintenance.Adaptability to diverse working conditions
With small working radius, it is suitable for work in a narrow area, and has been used widely in ditch backfilling, underground work, construction of road corners and rural construction etc.| External dimensions | 1120*755*1100mm |
| Engine brand | Changchai |
| Power/speed | 8/3600kW/rpm |
| Operating weight | 870kg |
| Front and Rear Static Linear Loads | 52/54N/cm |
| Vibration frequency low/high | 60Hz |
| Excitation force | 20kN |
| Amplitude | 0.5mm |
| Gradeability | 0.3 |
| Speed | 0-1.2，0-3.6km/h |
| Emissions | Eu stage IIIndicated as per China standards |
