| Engine model | WP4.1 |
| Rated power/speed | 74/2200kW/rpm |
| Machine dimension | 7230×2375×3150 standard |
| Machine weight | 7500standard |
| Tire specification | 16/70-24/13.00-24 |
| Ground clearance | 550Front axle |
| Wheel track | 1900mm |
| Axle distance between front and rear | 5135mm |
| Drive speed, forward | 5、8、11、17、24、38km/h |
| Drive speed, reverse | 5、11、24km/h |
| Traction force f=0.75 | ≥39kN |
| Maximum gradeability | ≥25% |
| Tire inflation pressure | 300kPa |
| Work system pressure | 16MPa |
| Transmission box pressure | 1.4—1.8Mpa |
| Maximum steering angle, front wheel | ±49° |
| Allowable tilt angle, front wheel | ±17° |
| Maximum oscillation, front axle | ±15° |
| Maximum steering angle, frame | ±27° |
| Minimum turning radius | 6m |
| Maximum lift above ground | 310mm |
| Maximum cutting depth | 350mm |
| Maximum tilt angle | 45° |
| Cutting angle | 28—70° |
| Swivel angle | 120° |
| Length x Height | 3048×450mm |
| Coolant | 50L |
| Fuel tank | 260L |
| Engine | 18L |
| Transmusswon box | 26L |
| Drive axle | 28L |
| Hydraulic oil | 50L |
