| Engine model | WP8G178E671 |
| Rated power/speed | 131/2200kW/rpm |
| Machine dimension | 9230×2625×3470standard |
| Machine weight | 15000standard |
| Tire specification | 17,5-25 |
| Wheel track | 2156mm |
| Axle distance between front and rear | 6489mm |
| Minimum ground clearance, front axle | 610mm |
| Wheel base between middle and rear | 1568mm |
| Drive speed, forward | 5、8、13、18、30、47km/h |
| Drive speed, reverse | 5、13、30km/h |
| Traction force f=0.75 | 79kN |
| Maximum gradeability | ≥40% |
| Tire inflation pressure | 260kPa |
| Maximum steering angle, front wheel | ±48° |
| Allowable tilt angle, front wheel | ±18° |
| Maximum oscillation, front axle | ±16° |
| Maximum oscillation, balance box | ±15° |
| Maximum steering angle, frame | ±25° |
| Minimum turning radius | 7.4m |
| Maximum tilt angle | 90° |
| Cutting angle | Front 40; Rear 5° |
| Length x Height | 3660X610mm |
| Coolant | 50L |
| Fuel tank | 300L |
| Engine | 24L |
| Balance box | 120L |
| Drive axle | 36L |
| Hydraulic oil | 120L |
