| Engine model | QSB6.7 |
| Rated power/speed | 178/2200kW/rpm |
| Machine dimension | 9343×2625×3432standard |
| Machine weight | 17000standard |
| Tire specification | 17.5--25 |
| Wheel track | 2156mm |
| Axle distance between front and rear | 6527mm |
| Wheel base between middle and rear | 1538mm |
| Drive speed, forward | 5/8/11/18/25/40km/h |
| Drive speed, reverse | 2005-11-25 00:00:00km/h |
| Traction force f=0.75 | ≥88kN |
| Maximum gradeability | ≥25% |
| Tire inflation pressure | 260kPa |
| Work system pressure | 26MPa |
| Transmission box pressure | 1.85-2.2Mpa |
| Maximum steering angle, front wheel | ±48° |
| Allowable tilt angle, front wheel | ±17° |
| Maximum oscillation, front axle | ±15° |
| Maximum oscillation, balance box | Front 15 rear 15° |
| Maximum steering angle, frame | ±25° |
| Minimum turning radius | 7.6m |
| Maximum lift above ground | 452mm |
| Maximum cutting depth | 755mm |
| Maximum tilt angle | 90° |
| Cutting angle | Front 40 rear 5° |
| Swivel angle | 360° |
| Length x Height | 3965×610mm |
| Coolant | 50L |
| Fuel tank | 390L |
| Engine | 24L |
| Transmusswon box | 38L |
| Balance box | 75 eachL |
| Drive axle | 25L |
| Hydraulic oil | 105L |
