| Engine model | QSB6.7 |
| Rated power/speed | 194/2200kW/rpm |
| Machine dimension | 9370×2800×3522standard |
| Machine weight | 19000standard |
| Tire specification | 20.5-25 |
| Ground clearance | 620Front axle |
| Wheel track | 2280mm |
| Axle distance between front and rear | 6531mm |
| Wheel base between middle and rear | 1622mm |
| Drive speed, forward | 5、8、11、19、26、47km/h |
| Drive speed, reverse | 5、11、26km/h |
| Traction force f=0.75 | ≥99kN |
| Maximum gradeability | ≥25% |
| Tire inflation pressure | 350kPa |
| Work system pressure | 22MPa |
| Transmission box pressure | 1.85-2.2Mpa |
| Maximum steering angle, front wheel | ±48° |
| Allowable tilt angle, front wheel | ±17° |
| Maximum oscillation, front axle | ±15° |
| Maximum oscillation, balance box | Front 10, rear 10° |
| Maximum steering angle, frame | ±20° |
| Minimum turning radius | 7.9m |
| Maximum lift above ground | 480mm |
| Maximum tilt angle | 90° |
| Cutting angle | 29—69° |
| Swivel angle | 360° |
| Length x Height | 4270×610mm |
| Coolant | 50L |
| Fuel tank | 270L |
| Engine | 24L |
| Transmusswon box | 38L |
| Balance box | 170L |
| Drive axle | 44L |
| Hydraulic oil | 190L |
