| Max. Working Height | 44.06m/144ft 7in |
| Max. Platform Height | 42.06m/138ft |
| Max. Operating Range(+0.6m) | 22.97m/75ft 4in |
| Max. Up And Over Clearance | 18.80m/ 61ft 8in |
| Max. Down Probing Depth | 9.65m/31ft 8in |
| Overall Length(Stowed) | 13.52m/44ft 4in |
| Overall Width(Axle Expanded) | 4.17m/13ft 8in |
| Overall Width(Axle Retracted) | 2.44m/8ft |
| Overall Height(Stowed) | 3.10m/10ft 2in |
| Transport Size(Length×Width×Hight) | 11.97m×2.44×3.10m/39ft 3in×8ft×10ft 2in |
| Platform Size(Length×Width) | 2.44m×0.91m/8ft×2ft 12in |
| Turntable Tailswing(Axle Expanded) | 2.47m/8ft 1in |
| Turntable Tailswing(Axle Retracted) | 3.45m/11ft 4in |
| Ground Clearance(Stowed/Raised) | 0.40m/1ft 4in |
| Wheelbase(Axle Expanded) | 4.07m/13ft 4in |
| Wheelbase(Axle Retracted) | 4.27m/14ft |
| S.W.L(Unrestricted/Restricted) | 272kg/600lb |
| Max. Occupants | 2 |
| Gradeability | 0.45 |
| Travel Speed(Stowed) | 6.0km/h / 3.73mph |
| Travel Speed(Raised) | 1.1km/h / 0.68mph |
| Max. Working Slope | 5° |
| Turret Rotation | 360°Continuous |
| Platform Rotation | 180° |
| Jib Movement | 226°(+60°,-166°) |
| Main Boom Maximum Angle | 72.23° |
| Turning Radius(Inside/Outside)Axle Expanded | 2.99m/5.41m/10ft/17ft 9in |
| Turning Radius(Inside/Outside)Axle Retracted | 8.27m/10.85m/27ft 1in/35ft 7in |
| Tyres | 445/50/D710 |
| Overall Weight | 23950kg/52801lb |
| Lithium Battery | 358.4V/173Ah |
| Charger | 360V/30A |
| Emergency Power System | 12V |
| Lifting Motor | 360V/30kW |
| Range Extended Engine | Kubota D1105/18.2kW |
| Hydraulic Tank | 230L/60gal |
