| Working Height | 20500mm |
| Lift capacity | 300 kg (unlimited)kg |
| Weight | 8350kg |
| Overall dimension-Stowed | 9800x2490x2640mm |
| Overall dimension-Transportation | 7400x2270x3000mm |
| Dimension of working platform | 1830x760x1150mm |
| Wheelbase | 2500mm |
| Fly jib length | 1850mm |
| Ground clearance | 300mm |
| Max.Platform height | 18.5m |
| Max.Working range | 13.2m |
| Max.Occupants | 2 |
| Max.Working slope | X-5°/Y-5° |
| Telescopic boom luffing range | -5～+76° |
| Flying jib luffing range | -65～+70° |
| Turntable rotation | 360° |
| Platform rotation | 160° |
| Drive speed | 4.8km/hstowed |
| Drive speed | 0.6 km/hUp or extended |
| Min.Turning radius | 3100mm/5000mminside/outside |
| Turntable tailswing | 1630mmstowed |
| Max.Gradeability | 45% (24°) |
