| Working Height | 34500mm |
| Lift capacity | 300kg(unlimited)/460kg(limited)kg |
| Weight | 18700kg |
| Overall dimension-Stowed | 13780x2490x2980mm |
| Overall dimension-Transportation | 13180x2490x3000mm |
| Dimension of working platform | 2400x900x1150mm |
| Wheelbase | 3200mm |
| Fly jib length | 1850mm |
| Ground clearance | 320mm |
| Max.Platform height | 32.5m |
| Max.Working range | 20.5m |
| Max.Occupants | 3 |
| Max.Working slope | X-3°/ Y-3° |
| Telescopic boom luffing range | -4°~ +73° |
| Flying jib luffing range | -65°~ +70° |
| Turntable rotation | 360° |
| Platform rotation | 160° |
| Drive speed | 6km/hstowed |
| Drive speed | 0.6km/hUp or extended |
| Min.Turning radius | 4600mm/6500mminside/outside |
| Turntable tailswing | 1980 mmstowed |
| Max.Gradeability | 45% (24°) |
